UltraRAE 3000 +

• Alarm Type
  • Audible, Visual, Vibrating
• Sensor Range
  • VOC (0-10000ppm), Benzene (0-200ppm), Butadiene (0-200ppm)
• Minimum Temperature
  • -20 degree Celsius
  • -4 degree Fahrenheit
• Humidity Range
  • 0%-95%
• Benefits
  • • Versatile VOC or Benzene-Specific modes
• Sub-Category
  • Premium-Gas
• Maximum Temperature
  • 50 degree Celsius
  • 122 degree Fahrenheit
• Weight
  • 738 gram
  • 26 ounce av [Invisible]
• Standards
  • US and Canada: CSA, Classified as Intrinsically Safe for use in Class I, Division 1
• Sampling Pump Range
  • 100ft (30m)
• Brand
  • RAE
• Wireless Technology
  • MESH, BLE
• Gas Type
  • VOC, Benzene, Butadiene
• Datalogging
  • Standard 6 months at one-minute intervals
• Battery Run Time
  • 16
• Warranty
  • 3 years for 10.6 eV lamp, 6 months for
• Ingress Protection
  • IP65
• User Options
  • • Alarms latching with manual override or automatic reset
• Instrument Size
  • 10” L x 3.0” W x 2.5” H (25.5 x 7.6 x 6.4 cm)

The UltraRAE 3000 is the most advanced Compound-Specific Monitor on the market. Its Photoionization Detector’s (PID)extended range of 0.05 to 10,000 ppm in VOC mode and 50 ppb to 200 ppm in benzene-specific mode makes it an ideal instrument for applications, from entry pre-screening during refinery and plant maintenance to hazardous material response, marine spill response and refinery down-stream monitoring.

• Dual detection mode for total benzene exposure assessment: 60-second snapshot or 15-minute STEL measurement
• High sensitivity to benzene (as low as 50 ppb) provides a lower detection range for future benzene exposure limits
• Lower risk of false alarms through advanced speciation method
• Total VOC measurement mode with extended range of 0.05 to 10,000 ppm

• Proven PID technology
• 3-second response in VOC mode or 60 seconds in compound-specific mode
• Extended range up to 10,000 ppm (in VOC mode) with improved linearity
• Built-in humidity sensor
• Automatic temperature-controlled sampling time calculation
• Highly specific readings, combining a 9.8eV UV lamp and RAE-Sep™ benzene tube
• New sampling probe design provides instant tube-breakthrough visibility
• Versatile VOC or Benzene-Specific modes
• Real-time wireless with built-in Bluetooth and optional RAELink3 portable modem
• Integrated RAE Systems Correction Factors list for more than 200 compounds

Easy to Use:

• Large graphic display
• Multi-language support
• Easy access to lamp, sensor and battery in seconds without tools

Low Cost of Ownership:

• Inexpensive analysis using low-cost RAE-Sep tubes
