Type 010 Triangle frame |
|
Length of tape | 15 - 1000m |
Dimensions of probe | ∅ 15 mm, Length: 195 mm |
Power supply | 4 x 1,5 Volt; Size: C |
Type 025 |
|
Length of tape | 15 - 60 m |
Dimensions of probe | ∅ 15 mm, Length: 195 mm |
Power supply | 4 x 1,5 Volt; Size: C |
Type 015 Hand device |
|
Length of tape | 15 - 50 m |
Dimensions of probe | ∅ 15 mm, Length: 195 mm |
Power supply | 4 x 1,5 Volt; Size: C |
Type 020 Mini |
|
Length of tape | 5 - 10 m |
Dimensions of probe | Ø 15 mm, Length: 70 mm |
Power supply | 1 x 9 Volt / Size: PP3 |
All models |
|
Material of probe | Made of stainless steel and nickel-plated brass, easy to clean |
Recommended storage temperature | +5°C to +30°C Battery gentle |
Protection class of probe | IP 68, permanently pressure-tight |
Protection class for tape drum | IP 64, splash-proof |
Accessories |
|
Acoustic signal | Option for: Type 010, 025 and 015 Already integrated in Type 020 |
Bottom sensor for additional hole- depth measurement | Option for: Type 010, 025 and 015 Type 020: not available with this accessory |
Probe Ø 10 mm, length 175 mm | Option for: Type 010, 025 and 015 Type 020: not available with this accessory |
Protection bag (adapted to the respective measuring tape length) | available as accessory for all models |
- Water level measurements in electrically conductive liquids in gauge pipes, groundwater wells and tanks
- Long-term observations for periodic check measurements
- Inspection of installed groundwater dataloggers
- Continuous water level detection during pumping tests
- Additional exploration of the well-depth with the bottom sensor (accessory)
The Water Level Meter is standard equipment for the exact measurement of water level in groundwater observation wells. The mobile devices are characterized by a simple, fast and reliable measurement acquisition. The different versions allow you to select the right measuring device according to your individual requirement for cable length or ease of use.
By default, all Water Level Meters are equipped with optical signaling when in contact with water. Optionally, the units can be extended with an acoustic signal on contact with water and a bottom sensor for depths measurement of the groundwater well. Our measuring instruments have been in use for many years worldwide and are a guarantee for robustness and precise measured values in harsh field conditions.
- No annoying components or brackets when cranking
- Robust construction with low weight
- 4 different models for individual requirements and applications
- Variable cable lengths from 5 to 1000 m available
- Bottom sensor for ground- sounding (accessory)
